Solder paste is a paste mixture formed by mixing solder powder, flux and other surfactants and thixotropic agents. It is a new welding material produced by the smt patch process and is an important factor to ensure the reliability of reflow welding process. It is mainly used in pcb surface welding field of smt industry. The following is an Apex-New Material solder paste manufacturer to briefly introduce the use of solder paste and precautions.

First, the use of solder paste

1, the solder paste must be stored in the refrigerated space of 2-8 ° C, before use, the original solder paste from the cold room, need to be at room temperature 20-25 ° C for 4h or more, in the solder paste bottle status bar marked with thawing time, and according to the production needs, do a good job in the use of management table registration;

2, the long-term unopened solder paste must be stirred for 3-5 minutes before use, you can use manual mixing or automatic solder paste mixer to make it uniform, in order to use;

3, if it is found that the solder paste is dry and does not meet the production standards, you can add the appropriate thinner for the solder paste to stir, and then use;

4, in use according to the production requirements, how much to take how much, has been opened and not used completely should be put back in the refrigerator, if improperly stored, placed at room temperature for more than 12h, the solder paste to be scrapped;

Second, the use of solder paste precautions

1. The opening time should be as short as possible. After taking out enough solder paste, the inner cover should be covered immediately.

2. After removing the solder paste, cover the inner cover immediately and press down hard to squeeze out all the air between the cover and the solder paste, so that the inner cover and the solder paste are in close contact.

3, the extracted solder paste should be printed as soon as possible: the printing work should be continuous without pause, and the extracted solder paste should be printed as soon as possible

4. Disposal of the excess solder paste that has been taken out: after all printing is completed, the remaining solder paste should be recycled into a special bottle as soon as possible, and stored in isolation from the air as precautions 2. The remaining solder paste cannot be put back into the unused solder paste bottle.

5, the operator should pay attention to avoid direct contact between the solder paste and the skin.
